Combined with a 1000m laser rangefinder and two interchangeable IR emitters, this all-in-one binocular can be used for hunting, bird watching, animal search, rescue and marine scenarios.
Main features
- 640 × 512 pixel thermal detector with 12 μm pitch
- High sensitivity thermal module with NETD
- 35 mm, F1.0 thermal lens with a detection range of up to 1800 m (6,000 ft)
- Ultra-high-resolution 4K CMOS sensor: 3840 × 2160
- 0.49-inch OLED display with 1920 × 1080 resolution
- Two interchangeable 850 nm and 940 nm IR illuminators, and laser rangefinder with 1000 m range
- More than 8 hours of continuous operation with replaceable battery
- Lightweight 798 g, with a compact, ergonomic design
The world's leading dual-spectrum binoculars change the way you hunt during the day and night, especially at dusk. The HIKMICRO HABROCK 4K-60 binocular is an improved upgrade of the celebrated HABROCK 640 aimed at experienced hunters in both daytime and dusk hunting.
Technical Specifications
Thermalmodule
Image sensor: Uncooled VOx focal flat arrays
Maximum resolution: 640 × 512
Frame rate: 50 Hz
Pixel spacing: 12 μm
Spectral response band: 8 μm to 14 μm
NETD: Less than 20 mK (@25°C), F#=1.0
Lens (focal length): 35 mm, F1.0
Focusing mode: Focusing ring
Detection range: 1800 m
Minimum focusing distance: 3.5 m
Magnification: 3.0 × to 22.0 × (7.3 ×)
Field of view (H × V), degrees / m at 100 m: 12.5° × 10.1° / 22.0 m × 17.6 m
Optical module
Image sensor: 1/1.8'' progressive scan CMOS
Maximum resolution: 3840 × 2160
Focal length 60: mm, F2.2
Minimum operating distance: 3 m
Focusing mode: Focus ring
Magnifications: From 5.5 × to 22.0 × (4 ×)
Field of view (H × V), degrees/ m at 100 m: 7.3° × 4.1° / 12.6 m × 7.2 m
Intelligent IR: Yes
Illuminator wavelength: IR 940 nm (default) and 850 nm (interchangeable)
Night vision range: 400 m
Switchable IR illuminator: Yes
Image Display
Display: 0.49 inches, OLED, 1920 × 1080
Palettes: Thermal: Black Hot, White Hot, Red Hot, Fusion; Optical: Day, Night, Auto
FFC (Flat Field Correction) Mode: Auto, Manual, External Correction
Exit pupil: 8 mm
Interpupillary distance: r 15 mm
Diopter (Range): -5 D to +3 D
Brightness adjustment: Yes
Tint adjustment: Cool, warm
Contrast adjustment: Yes
Zoom Pro: Yes
System
Video recording: Yes
Snapshot capture: Yes
Audio recording: Yes
Standby mode: Yes
Storage: Built-in EMMC (64 GB)
PIP (Picture in Picture): Yes
Access Point: Yes
Hot Track Yes
Digital magnetic compass: Yes
GPS: Yes
Local Album: Yes
Power Supply
Battery type: Rechargeable and replaceable Li-ion 18650 battery
Battery operating time: ≥8 h (25°C, with hotspot off)
C-type power supply: 5 V DC, 2 A
Support external power supply, support direct charging
General
Protection level: IP67
Dimensions: 138.1 mm × 68.5 mm × 222.4 mm (5.44" × 2.7" × 8.75")
Operating temperature: -30°C ~ +55°C (-30°C ~ +55°C)
Weight: 798 g without battery
Interpupillary adjustment range: 60 mm to 74 mm (60 mm to 74 mm)
Mounting adapter : 1/4"-20-UNC
Laser rangefinder
Laser safety class Class 1:
Wavelength: 905 nm
Maximum measuring range: 1000 m
Measuring accuracy: ±1 m
Minimum measuring range: 10 m
Dimensions
COMPLIANCE NOTICE:
Thermal series products may be subject to export controls in various countries or regions, including but not limited to the United States, the European Union, the United Kingdom and/or other member countries of the Wassenaar Arrangement. We recommend that you consult with a legal or compliance expert or local government authorities for possible export licensing requirements if you intend to transfer, export or re-export Thermal Series products between different countries.
