CCD camera ZWO ASI174MM Monochrome

Name: CCD camera ZWO ASI174MM Monochrome
Brand: ZWO
SKU: ZWOASI174MM
Price: 516.49 EUR
Availability: PreOrder

Reference ZWOASI174MM

Stock at Supplier

516.49 537.19 -20.70

VAT excluded Shipping 5/7d

The new high quality astrophotography camera ZWO ASI174 incorporates a large, high resolution CMOS sensor. This camera is a very good alternative for all astrophotographers who attach the utmost importance to obtaining a wide field of view in their shots.

Order it before 9 hours and 27 minutes and receive it between on Thursday, 12 February and Thursday, 19 February with UPS - Resto del mundo

Delivery Options

Carrier		Description	Estimated Delivery
	UPS - Resto del mundo	UPS - Rest of the World	Thursday, 12 February - Thursday, 19 February

UPS - Resto del mundo

UPS - Rest of the World

Estimated delivery:
Thursday, 12 February - Thursday, 19 February

✖

Description
Product Details

CCD camera ZWO ASI174MM Monochrome.

The new high quality astrophotography camera ZWO ASI174 incorporates a large CMOS sensor with high resolution. This camera is a very good alternative for all astrophotographers who attach the utmost importance to obtaining a wide field in their shots.

The applications in which this camera excels are:

- - - - Planetary photography
      - Lunar photography
      - Solar photography (with appropriate filter)
      - Deep sky photography (camera is not cooled, but the CMOS sensor offers good response with very low noise)
      - Self-tracking camera

System requirements:

- - - - Computer with USB 3.0 available and supported by the operating system

Technical features:

- - - - Sensor: 1 / 1.2 "CMOS IMX174LLLJ / IMX174LQJ
      - Resolution: 2.3 mega pixels 1936x1216
      - Pixel size: 5.86 micrm
      - Sensor size: 13.4mm x 11.34mm
      - Exposure range: 32 microns - 1000 s
      - ROI: Supported
      - Auto-guiding port: ST-4
      - Interface: USB 3.0 / USB 2.0 (USB 3.0 highly recommended)
      - Software requirements: USB 3.0
      - Bit rate: 12-bit output (12-bit ADC)
      - Adapter: 2"/ 1.25" / M42X0.75
      - Dimensions: ⌀62 mm x 41 mm
      - Weight: 140 g
      - Working temperature: -5°C to 45°C (-4°F to 113°F)
      - Storage temperature: -20°C to 60°C (-4°F to 140°F)
      - Working relative humidity: 20% to 80%
      - Storage relative humidity: 20% to 95%
      - Max. Resolution: 1936 X 1216 (@ 128 FPS)

CCD Camera ZWO ASI174MM Monochrome.
